Pulp Pump

  • 505
Product Review | Top Rated

Pulp pump is a kind of machinery widely used in the paper industry. The two-phase flow pulp pump adopts the principle of "relative suction and relative blockage" in the two-phase flow theory for the h

    Additional Information

  • Color: Default Color
  • Size: Default Size
  • Origin: China
  • Usage: Default Usage
  • Type: Default Type
  • Efficiency: 99.9% Type

Description:

Pulp pump is a kind of machinery widely used in the paper industry. The two-phase flow pulp pump adopts the principle of "relative suction and relative blockage" in the two-phase flow theory for the hydraulic design of the pump, so that the hydraulic performance of the pump flow parts conforms to the law of solid-liquid two-phase flow, thereby reducing the scouring and wear of the slurry on the flow parts, and greatly improving the work efficiency and service life of the pump

1. High efficiency and energy saving: the operating efficiency is 3-10 percentage points higher than that of ordinary pulp pumps, and the energy saving and consumption reduction are 15-30%.

2. Good cavitation performance and long life: the actual service life can be increased by 2-3 times compared with ordinary pulp pumps;

3. High concentration and no blockage: the concentration of conveyed pulp can reach 6%;

4. Reasonable structure and convenient maintenance: the pump head part adopts the front and rear door opening structure, and the pump can be disassembled and repaired without disassembling the pipeline during maintenance, just moving the motor backwards.

Applicable industries: 1. Paper industry: used for the circulating transportation, lifting and pressurization of the medium in the industrial process of pulp and alkali recovery with a concentration of less than 6%; 2. Sugar industry: used for conveying syrup with a concentration of less than 4% and a viscosity of less than 150mm2/s; 3. Urban sewage industry: used for the circulating transportation, lifting and pressurization of the medium in the sewage treatment process.
